S3165LX.b - Electric Locking System

Product SKU: S3165LX.b

0.00

RFQ ONLY

Quantity

Product Details

Application

The S3165LX.b system includes several versions of a system designed for locking, unlocking and propelling sliding doors in safety vestibules, in dayrooms or in high-traffic corridors. Each S3165LX.b model utilizes an electric motor to operate the door through a rack and pinion drive mechanism. Doors are locked at top and bottom in both the open and closed positions by means of a concealed vertical lock bar at the rear jamb of the door. The vertical lock bar is deadlocked at a third locking point inside the horizontal cover box above the door. Standard clear door opening widths available are 3’0” to 6’0’’ (914 to 1829mm).

Function

Electric - A remote switch activates a motor which raises a vertical lock bar and propels the door open or closed. Individual lamp indicators on the control panel show locked / unlocked condition.
Mechanical - Manual unlocking is provided for each device. After being manually released, door movement is by hand. The door automatically deadlocks when moved to the fully open or closed position.
Standard Features
• Full remote control unlocking & movement of door
• Obsero control module
• Bottom door guide
• Door hanger
• Manual release in cover box
• Sloped-front cover box
• Hinged cover panel for maintenance access
• Vertical lock bar assembly
• Lock Open Position
• Integrated Bluetooth / Internal Antenna
• Indications - Door & lock bar position indications
• Prime paint finish
Optional Features:
• Manual release in cover box with 1010A paracentric lock
• Pilaser release (P-1 or P-2)
• Electric key switch - paracentric or mogul (PK-1 or PK-2 / PKM-1 or PKM-2)
• Flat top cover boxes
• Hot dip Galvanized (G)
• 3 hour fire rated (UL)
